Video Cables VGA SVGA XGA SXGA WUXGA High Resolution Angled 45 Degrees Monitor Cord How To

45 Degree Angled Connector VGA Monitor Cable

NTI Part #: VEXT-45D-xx-Group
VEXT-45D-xx
VEXT-45D-xx
NTI Part #: VEXT-45D-xx-Group
Extend a VGA monitor up to 25 feet at high resolutions up to 1920x1200.
Ideal for applications where space is tight.

Talk to a live agent

Scroll Down to Get Quote

Overview

  • No ghosting and no degradation - guaranteed.
  • Angled 45 degree connector enables easy installation in tight spots.
  • Diameter: 0.22".
  • Supports 1920x1200 (WUXGA) video resolution up to 25 feet.
  • Three 75 ohm micro coaxial cables.
  • The shield consists of mylar foil, braided shield and drain wire.
  • Drain wire and braid connected to connector shell.
  • Male 15HD to female 45 degree angled 15HD extension VEXT-45D-xx.
  • Available lengths: 3/6/10/15/25 feet.

(0)45 Degree Angled Connector VGA Monitor Cable - Male-Female

NTI Part # Length Qty
VEXT-45D-6 6 feet
VEXT-45D-10 10 feet
